BODY : STANKO

Max.dia. of gear blank mounted : 1000mm

Max.width of gear rim cut :160mm

Max.dia. of gear rim cut :
– External gear : 800mm
– Internal gear : 1000mm

Module of gear cut :
– Minimum : 1mm
– Maximum : 12mm

Diameter of TABLE : 800mm

Max.Shaping cutter nominal pitch : 200mm

Cutter Fastening Spindle nose : NO.5

Max.Spindle Stroke : 200mm

Range of spindle double- stroke : 33+188 mm/min

Size (L x W x H ) : 3100 x 1800 x 3500
