Specification

• Grinding length : 660mm
• Normal distance between centres (centres at the back) : 950mm
• Max. distance between centres (centres inside clamping head) : 1,330mm
• Height of Centers : 180mm
• Workpiece , min./max. : 10~350mm
• Workpiece speeds, infinitely variable : 0.3 ~ 52 rpm
• Lead range, min./max. : 0,1 ~ 999mm
• Max. lead angle : +/- 60°
• Pressure angle : 5 ~ 90°
• No. of starts : 1 ~ 99
• Grinding depth : 100mm
• Grinding wheel dimensions, x width : 500 x 63mm
• Grinding wheel speeds, infinitely variable : 75 ~ 2,400 rpm
• Grinding Spindle drive, approx. : 48 kW
• Total electric load : 100 kW – 380 V – 50 Hz
• Weight complete Unit : 12,500kg
