Specification

• Max. wheel diameter 180 mm
• Gear width 45 mm
• Max. module 4
• Min. module 0,5
• Stroke length max. 0 – 52 mm
• Spindle taper innen MK 4
• Table diameter 160 mm
• Table bore diameter 75 mm
• No. of strokes 355 – 630 Hub/min
• Feed range 0,008 – 0,4 mm/Hub
• Dimensions of the machine 2300 x 1500 x 2360 mm
• Weight of the machine 2500 kg
