Specification

• Max. Pitch Diameter: 8″ (Internal & External)
• Max. Diametral Pitch: 5/7 Spur; 6 Helical
• Max. Face Width: 1 1/2″ Internal; 2″ External
• Max. Stroke: 2-1/4″
• Max. Helix Angle W/Standard Guides: 38 Degrees 41′
• Diameter of the Cutter Spindle 3-3/8″
• Speeds Six from 200 to 600 strokes per minute
• Overall Dimensions: 66″L x 44″W x 81″H
• Net Weight W/Motors: 6,750lb
